Module Type:Digital DC Input Module
Number of Channels:8
Operating Voltage Range:5VDC to 30VDC
Input Range:-20mA to +20mA
Current Consumption:≤10mA per channel
Signal Conditioning:Common mode rejection ratio > 100dB
Environmental Conditions:Operating temperature: -20°C to +55°C, Storage temperature: -40°C to +70°C
Dimensions:146mm (W) x 74mm (D) x 53mm (H)
Weight:Approx. 0.3kg
The Allen-Bradley 1746-IV8 DC Input Module is designed to withstand harsh industrial environments, offering superior reliability and robustness in demanding conditions. It features high signal integrity with a common mode rejection ratio greater than 100dB, ensuring accurate data transmission even in noisy environments.
This module supports a wide range of input voltages (5VDC to 30VDC) and currents (-20mA to +20mA), making it compatible with various sensors and transducers commonly found in industrial setups. Its low current consumption per channel (≤10mA) helps minimize power usage, contributing to efficient system operation.
Ease of installation and maintenance are key aspects of this module, designed with Allen-Bradley’s user-friendly standards in mind. It can be quickly integrated into existing PLC networks, reducing downtime and facilitating seamless system upgrades.
Incorporating advanced signal conditioning technology, the 1746-IV8 ensures minimal signal distortion, which is critical for accurate data interpretation in complex industrial automation scenarios. This precision is particularly beneficial in applications requiring high-speed processing and decision-making.
The module’s compact size (146mm (W) x 74mm (D) x 53mm (H)) and lightweight design (Approx. 0.3kg) make it an ideal choice for space-constrained industrial settings. Its durability and small footprint contribute to efficient workspace utilization without compromising performance.
